TASCAM DR-100 MK II - Handheld Digital Recorder

TASCAM
Regular Price Rs.50,000.00 Sale Price Rs.60,000.00 Unit price: Rs.0.00

24bit/96kHz Linear PCM Recorder

DR-100MKII

Enhanced hardware and audio quality worthy of being called a "high-end model"
Professional linear PCM recorder supporting 24bit/96kHz

The DR-100MKII is a high-end linear PCM recorder within TASCAM’s handy recorder lineup that supports the 24bit/96kHz format.
By leveraging TASCAM’s long-career as a professional recording device brand, and incorporating on-site feedback, a refined recorder worthy of being called a “handy high-end recorder” was born.

DR-100MKII



Improved quality while maintaining the usability of the DR-100

The enhanced hardware composition built on a conventional model, the DR-100, is the biggest feature of the DR-100MKII.
The solid body and equally large independent left/right adjustable rotary input volume knob allows for precise adjustment due to its larger size.
Needless to say, it is also capable of adjusting level differences between left and the right.
Mechanical switches used for secure operation and speedy setups have been distributed across six functions.
A digital input jack is located on the side, with its line output independent from the headphones, allowing for a high level of sound quality line output that would be impossible with shared connectors.
The external inputs include unbalanced line input in addition to a locking XLR input connector, compatible with a +4dBu line level input. Headroom of 20dB has been secured, supporting audio output of images for broadcasting and acoustic equipment.

DR-100MKII
DR-100MKII

Higher sound quality attained by implementing a microphone amplifier that adopts high sound quality analog circuits and discrete parts

The DR-100MKII achieves detailed sounds through its meticulously designed high sound quality analog circuit.
By equipping a microphone amplifier with discrete parts has further improved on the S/N ratio.
As a whole, an S/N ratio of 92dB and a HD+N of 0.01% (max) was achieved.
In addition to the unidirectional high sound quality stereo condenser microphone, the omnidirectional stereo microphone useful for such purposes as recording meetings has improved sound qualities compared with conventional models.

Factory-installed remote controller that eliminates touch noise

Furthermore, a remote controller that eliminates noise from touching the unit has been factory-installed.
In addition to enabling operations via wireless infrared, a 2WAY remote control has been included that allows for wired operation in case users wish for secure, reliable operation.
Other accessories that are included are a soft case useful for carrying the device around, Li-ion batteries, and a fur windscreen.
When the DR-100MKII needs to be run for a long period of time, users can connect the device to the optional PS-P520 AC adapter and the BP-6AA external battery pack.

The DR-100MKII delivers high sound quality recording, a sense of security when working on-site, and high level of versatility that provides a reliable, high sound quality recording environment even in the most demanding sites.

DR-100MKII

High end model with advanced hardware, Professional 24bit/96kHz compatible linear PCM recorder

The rugged TASCAM DR-100mkII offers high-end recording features for musicians and engineers who demand more from their portable recorder. It features four built-in microphones - two cardioid and two omnidirectional - for great sounding recordings. A pair of XLR connectors accept microphone level signals with +48V phantom power for pro-grade condenser microphones, or balanced line-level signals (a new feature on the mkII). The mkII version also adds a S/PDIF digital input, locking connectors and more.

  • Total of 4 microphones including 2 unidirectional condenser microphones and 2 omnidirectional microphones
  • Locking XLR/TRS inputs compatible with +4dBu line level / +48V phantom power with 20dB of head room
  • Dual battery system that can use two different types of batteries; the exclusive Li-ion battery and standard AA batteries
  • Independent left/right adjustable large rotary input volume knob
  • Rugged aluminum body for use in extreme conditions
  • Digital input connector for lossless connection from playback devices
  • Mechanical switches allowing for simple and sure operation
  • High-quality output via the line level output connector, which is independent from the headphones connector
  • High-quality sound from discrete parts
  • AD/DA Audio4pro for professional audio
  • Built-in 0.4W monaural speaker for sound source confirmation
  • 128x64 pixel backlight LCD
  • SD/SDHC cards, which have broad versatility and are easy to use, can be used for recording media
  • 24bit/96kHz high sound quality linear PCM (WAV) recordings and long recordings as MP3 files are possible (96kHz is only possible in HS Mode)
  • Overdubbing function allows for new recordings to be overlapped onto recorded files *Overdub recording cannot be selected when prerecording is used
  • Level control function for adjusting the auto gain control and limiter
  • Three low cut filter levels that cut unnecessary low frequency noise such as from air conditioning equipment (40/80/120Hz)
  • Auto recording function that can detect the sound input signal level and automatically start recording
  • Prerecording function that can record up to 2 seconds prior to starting recording
  • REC DELAY function for delaying the start of a recording to avoid recording the sound of pressing the RECORD button
  • Mark function that can set up to 99 points for a single track
  • QUICK TAG function for quickly identifying files
  • File name format can be set to use a user-defined word or the date
  • Auto track incrementing function that automatically updates files while continuing to record (Detection source: Level, size)
  • Track incrementing function that creates new files at arbitrary locations during recording
  • Playlist function that registers files you want to play back
  • Repeat playback function (All/Single/A-B)
  • Tempo change (VSA) function for adjusting the speed from 50% to 116%, which is great for practicing music and studying languages (This function is not available in HS Mode)
  • Divide function for dividing files at specified locations (WAV files only)
  • Japanese language display for MP3 ID3 tag (Ver. 2.4) is possible
  • Audio file information such as the recording date/time and size can be confirmed
  • High-speed file transfer to a computer via USB 2.0
  • 2GB SD card is included
  • Strong metal tripod attachment screw-hole at the bottom on the unit
  • Includes the RC-10 wireless/wired remote control
  • Includes a soft case and windsock
  • Longer operation is possible by using the optional BP-6AA external battery pack
  • Operation is possible by AC power using the optional PS-P520 AC adapter
  • Mini USB cable included

Specification

Recording Media SD card(64MB to 2GB), SDHC card(4GB to 32GB)
File System FAT16/32
File Format WAV, MP3
Recording/Playback Format
WAV 44.1/48/96 (HS mode) kHz, 16/24-bit
Sampling frequency
STD mode 44.1k / 48k Hz
HS node 44.1k / 48k / 96k Hz
Quantization bit rate 16bit / 24bit
MP3
Sampling frequency 44.1k / 48k Hz
Recording bit rate 32k / 64k / 96k / 128k / 192k / 256k / 320k bps
Playback bit rate 32kbps to 320kbps
Number of Channels 2 channels(stereo)
Playback Speed Control (VSA) -50% to +16%(1% step)
Analog Inputs
MIC/LINE 1 IN Phantom Power Compatible
Connecter XLR-3-31 (1 : GND, 2 : HOT, 3 : COLD
MIC Switch is set to MIC
Input Impendance 2.1k ohms
Nominal Input Level -14dBu
Maximum Input Level +2dBu
LINE 1 Switch is set to LINE
Input Impendance 2.5k ohms
Nominal Input Level +4dBu
Maximum Input Level +24dBu
LINE 2 IN
Connetor 3.5mm(1/8") Stereo mini jack
Input Impedance 22 k ohms or more
Nominal Input Level -10dBV
Maximum Input Level +6dBV
Analog Output
LINE OUT (XLR LINE IN)
Connector 3.5mm(1/8") Stereo mini jack
Output Impendance 200 ohms
Nominal Output Level -14dBV
Maximum Output Level +6dBV
Digital Input
Connector 2.5mm(3/32") TRS jack
Format IEC60958-3(S/PDIF)
PHONES
Connector 3.5mm(1/8") Stereo mini jack
Maximum Output 25mW+25mW(32ohms loaded)
USB
Connector Mini-B type
Format USB2.0 HIGH SPEED mass storage class
REMOTE
Connector 2.5mm(3/32") TRS jack
Format Exclusive TASCAM RC-10/RC-3F
Built-in Speaker 0.4W (mono)
Power Supply Exclusive Li-ion battery (BP-L2),
2 AA batteries,
Exclusive AC adapter (PS-P520),
Exclusive external battery pack (BP-6AA)
Power Consumption 4W(MAX)
Battery operation time
(Recording)

Li-ion battery (BP-L2)
Built-in mics(UNI/OMNI)
Approx 5 hours(Recording WAV, 44.1kHz, 16 bit)
Alkaline batteries
(EVOLTA)
Built-in mics(UNI/OMNI)
Approx 2 hours 45 minutes(Recording WAV, 44.1kHz, 16 bit)
Ni-MH batteries
(eneloop)
Built-in mics(UNI/OMNI)
Approx 4 hours(Recording WAV, 44.1kHz, 16 bit)
Dimensions 3.15(W)×6.024(H)×1.378(D) inch
80(W)×153(H)×35(D) mm
Weight
(without batteries)
0.64lb
290g
Operating Temerature 0˚C to 4˚C
Included Accessories 2GB SD card, Exclusive Li-ion battery (BP-L2), USB connection cable, Exclusive soft case, Exclusive windsock, Wireless remote control (RC-10), Coin cell battery for confirming remote control operation, Wired remote control adapter, Wired remote control cable, Digital input conversion cable, Owner's Manual, Warranty card
